Wrap Custom Indoor/Outdoor Ceiling Fan DC Motor- Brushed Satin Brass

Fanimation
Wrap Custom Indoor/Outdoor Ceiling Fan DC Motor- Brushed Satin Brass

Part Number: MAD8530BS
UPC: 00840506114579
List Price:
$
504
99
/ / 1
($504.99 / 1)
WAS
$
Call for Price
  • Call Online Sales at 732-349-4100 for Availability
  • Expect more in around 09/09/2025
Quantity:
Changes Selections Above Finish...
Changes Selections Above Airflow Efficiency Low...
Changes Selections Above CFM Low...
Changes Selections Above Current Draw Low...
Return
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Print
Email
Product Overview
Info & Guides
Click Here to View Spec Sheet Details
Click Here to View Manual Sheet Details
Wrap yourself in style with this sophisticated ceiling fan from Fanimation. with many motor and blade finish combinations available, Wrap Custom is a versatile ceiling fan. LED and CCT Select Light kit, blades and motor sold separately. This ceiling fan is Damp Rated for indoor or outdoor use. It can also be controlled by using the Fanimation Wi-Fi fanSync application.
Specifications
Details
Product Height:
12.46"
Product Width:
44.00"
Product Length:
44.00"
Category:
Fans
Subcategory:
Ceiling Fans
Finish:
Brass
Option:
Energy Efficient , Outdoor , Damp Rated
Voltage:
100-120
Number of Blades:
3 Blades
Location Rating:
Damp Rated
Wattage:
8w
Category:
Motor
Finish:
Brushed Satin Brass
Option:
Energy Efficient , Outdoor
Family:
Wrap Custom
Voltage:
120 V
Air Flow CFM:
7141
Air Flow Efficiency:
200
Blade Pitch:
Varied
Canopy:
6.14 Dia x 2.55 H
Harmonized Codes:
8414.51.3000
Light Kit Included:
No
Motor Size:
158 x 22
Motor Type:
DC
Ship Carton Height:
7.6
Ship Carton Length:
16.34
Ship Carton Width:
8.86
Ship Weight:
14.99
Sold By:
EA
Warranty:
Limited Lifetime
Weight:
12.13
Airflow Efficiency Low:
404
Airflow Efficiency Medium:
552
Avg Airflow Efficiency:
211
Avg CFM Energy:
5114
Avg Energy Use:
24
Avg Estimated Yearly Energy Cost:
7
Avg Estimated Yearly Energy Cost on HIGH:
10
Cap Included:
Yes
Carton Cubic Feet:
0.64
Case Height:
7.6
Case Length:
16.34
Case Quantity:
1
Case Weight Pounds:
14.99
Case Width:
8.86
CEC Uploaded:
Yes
Ceiling To Blade Edge:
11.83
Ceiling To Bottom (No Light Kit):
12.46
Ceiling To Bottom (With Light Kit):
13.05
CFM Low:
728
CFM Medium:
4359
Country of Origin:
China
Current Draw High:
0.49
Current Draw Low:
0.04
Current Draw Medium:
0.13
DOE Classification:
LSSD
DOE-FTC Uploaded:
Yes
Downrod Length:
4.5
Energy Efficient:
Yes
Exempt from DOE Procedure:
No
Fan Energy Star 4:
Yes
Housing Diameter:
8.88
Included Control:
TR305
Included Control Type:
Handheld
Indoor:
Yes
Leadwire:
80
Location Rating:
Damp Rated
Max Ceiling Slope:
27
Max Length:
60
Max Width:
60
Motor Finish Method Type:
Painted
Motor Reversible:
Yes
Number of Blades:
3
Number Of Speeds:
16
Outdoor:
Yes
Prop 65 Description:
This product can expose you to chemicals including Lead which are known to the State of California to cause cancer and birth defects or other reproductive harm. for more information go to www.P65Warnings.ca.gov
Regulated Product:
Yes
Reverse Switch Location:
Control
RPM High:
138
RPM Low:
29
RPM Medium:
88
Safety Rating:
UL Approved, cUL Approved
Voltage Cycles:
60 Hz
Watts High:
36
Watts Low:
2
Watts Medium:
8
Manufactured By:
Fanimation
Other Details
  • CONTROL: Includes a Wi-Fi receiver and TR305 handheld remote with two 3V CR2032 batteries - Push buttons control 16 variable fan speeds
  • FINISH: Brushed Satin Brass ceiling fan motor from the Wrap Custom collection - Set of three Damp Rated blades available in multiple finishes (sold separately)
  • Infinite light levels, color temperature, fan/light timer, powering on/off, and fresh air, reverse, home away, safe exit modes
  • INSTALLATION: Mounts to flat or minimally sloped ceilings with the included 1-in diameter x 4.5-in length downrod.
  • LIGHTING: 18-Watt dimmable LED light kit with Correlated Color Temperature (CCT) Select technology and opal frosted glass available for added versatility (light kit sold separately)
  • LOCATION: This ceiling fan is Damp Rated for use in indoor and outdoor covered spaces exposed to moisture and humidity
  • Optional downrods are available in lengths up to 72 inches to adjust the fans height between 7-ft to 9-ft from the floor, ensuring maximum airflow.
  • POWER: The 16-speed, quiet and energy efficient DC motor can provide airflow up to 7,141 CFM
  • SAVINGS: Features a reversible motor, allowing you to switch the direction of your fan?s rotation and create energy savings
  • TECHNOLOGY: Includes fanSync Wi-Fi connectivity, allowing the fan to pair with most smart home devices
  • WARRANTY: Limited lifetime
